| CPU | AMD Socket AM5, support for AMD Ryzen™ 9000 / 8000 / 7000 Series Processors |
| Chipset | AMD B850 |
| Memory | Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s, 4 x DDR5 DIMM sockets up to 256 GB, Dual channel, Non-ECC support, AMD EXPO™ & XMP support |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics: 1 x DisplayPort (3840x2160@144 Hz, DP 1.4 & HDR), 1 x HDMI (4096x2160@60 Hz, HDMI 2.1, HDCP 2.3 & HDR) |
| Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | Realtek® Wi-Fi 7 RTL8922AE, 802.11 a/b/g/n/ac/ax/be, 2.4/5/6 GHz, BLUETOOTH 5.4, 11be 160MHz wireless, Windows 11 SV3 required for Wi-Fi 7 |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIEX16) PCIe 5.0 x16/x8/x4 mode, Chipset: 1 x PCIe x16 (PCIEX4, PCIe 4.0 x4), 2 x PCIe x16 (PCIEX1_1 & PCIEX1_2, PCIe 3.0 x1, share bandwidth with SATA3 0/1) |
| Storage Interface | 1 x M.2 (M2A_CPU, PCIe 5.0 x4/x2), 1 x M.2 (M2B_CPU, PCIe 4.0 x4/x2), 1 x M.2 (M2C_SB, PCIe 4.0 x2), 4 x SATA 6Gb/s, RAID 0/1/5/10 support for NVMe, RAID 0/1/10 for SATA |
| USB | CPU: 1 x USB Type-C, 2 x USB 3.2 Gen 2 Type-A (red), Chipset: 1 x USB Type-C internal, 4 x USB 3.2 Gen 1 (2 back, 2 internal), 4 x USB 2.0/1.1 back, 4 x USB 2.0/1.1 internal (Hub) |
| Internal I/O Connectors | 1 x 24-pin ATX, 1 x 8-pin ATX 12V, 1 x 4-pin ATX 12V, 1 x CPU fan, 1 x CPU fan/pump, 3 x system fan, 1 x system fan/pump, 3 x addressable RGB Gen2, 1 x RGB LED, 3 x M.2 Socket 3, 4 x SATA 6Gb/s, 1 x front panel, 1 x front panel audio, 1 x USB Type-C, 1 x USB 3.2 Gen1, 2 x USB 2.0/1.1, 1 x TPM header, 1 x reset button, 1 x reset jumper, 1 x Clear CMOS jumper |
| Back Panel Connectors | 1 x DisplayPort, 1 x HDMI, 1 x Q-Flash Plus, 4 x USB 2.0/1.1, 1 x PS/2, 2 x USB 3.2 Gen 2 Type-A (red), 1 x USB Type-C, 1 x RJ-45, 2 x USB 3.2 Gen 1, 2 x antenna connectors, 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM version), LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
